Supermicro A2SDi-8C+-HLN4F Server Motherboard - Socket BGA-1310 - Mini ITX

• DDR4 SDRAM compatible slot - Installs memory that reduces processor's idle time and enhances computer's performance
• Have a perfect symmetry of hardware components needed in the media server or NAS box with Mini ITX form factor

Technical Information

• Processor Socket: Socket BGA-1310
• Integrated Processor Type: Atom
• Integrated Processor Model: C3758
• Integrated Processor Core: Octa-core (8 Core)
• Number of Memory Slots: 4
• Memory Form Factor
  • DIMM
  • UDIMM
  • RDIMM
• Maximum Memory Supported: 256 GB
• Memory Technology: DDR4 SDRAM
• Memory Speed Supported
  • 1600 MHz
  • 1866 MHz
  • 2400 MHz
  • 2133 MHz
• Controller Type: Serial ATA/600
• Onboard Video: On-board Video Chipset
• Graphics Controller Model: AST2400
• Gigabit Ethernet: Yes
• Total Number of Expansion Slots: 1
• Total Number of PCI Express Slots: 1
• Number of PCI Express x4 Slots: 1
• Total Number of USB Ports: 2
• VGA: Yes
• Number of Network (RJ-45) Ports: 4
• Number of SATA Interfaces: 12
• Number of M.2 Interfaces: 1
• Total Number of Onboard USB Ports: 3
• Number of Onboard USB 3.0 Ports: 1
• Form Factor: Mini ITX
• Width: 6.7"
• Depth: 6.7"
• Package Contents
  • A2SDi-4C-HLN4F Server Motherboard
  • 2 x SATA Cables
  • 1 x I/O Shield
• Compatibility:

  Chassis (Optimized for A2SDi-8C+-HLN4F)

  • SC721TQ-250B
• Environmentally Friendly: Yes
• Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Package Contents

• A2SDi-4C-HLN4F Server Motherboard
• 2 x SATA Cables
• 1 x I/O Shield
