Vertiv Cybex SC900 Secure KVM

Vertiv Cybex SC900 Secure KVM | Dual Head | 4 Port Universal DisplayPort | NIAP version 4.0 Certified - Secure Desktop KVM Switches | Secure KVM Switch | Dual Head | NIAP Certified | Secure Keyboard | 2 to 8 Port, Secure Isolated Channels | Running up to UHD 4K at 60Hz | 3-Year Full Coverage Factory Warranty - Optional Extended Warranty Available

The Vertiv Avocent Cybex SC940DPH-400 secure desktop KVM switch provides secure connectivity across multiple resources. It lets users switch between computers with different security levels while preventing data leaks. Designed for security-conscious organizations, the SC940DPH-400 isolates each connected system, enforcing unidirectional data flow to safeguard sensitive information. It supports a maximum resolution of 3840 x 2160 at 60 Hz, delivering crisp, clear visuals. This KVM switch offers touchscreen support and biometric authentication for seamless, secure login on any connected computer, with built-in support for smart-card (CAC) and biometric readers. The four universal video ports (DisplayPort and HDMI) allow easy connection of up to two systems. Certified to the latest NIAP Common Criteria Protection Profile for Peripheral Sharing Switch (version 4.0), the SC940DPH-400 also features active intrusion detection and tamper-evident labels to alert users of unauthorized access.

• NIAP 4.0 Certified: Security: Secure 4-port KVM with always-on anti-tampering, NIAP 4.0 certified.
• Biometric Support: Authenticate on any computer with built-in Smart-Card and biometric support
• Versatile Video Support: Supports DP, HDMI, and DVI-I up to 3840 x 2160 resolution for HD visuals.
• Zero Delay Switching: Instant mouse and keyboard switching with emulation for lag-free transitions.
• Peripheral Isolation: Combines keyboard, mouse, and display into one setup for a clutter-free space.

Technical Information:

Device Overview

• Secure KVM switch (desktop form factor)

• Model: Cybex SC940

• Product line: Cybex 900 series

• Country of origin: United States

• TAA compliant

Video

• Max resolution: 3840 × 2160 (4K)

Power

• Input voltage: 100–240 VAC

Processor / KVM Functionality

• Device type: Secure KVM

• Number of computers supported: 4

• Local users: 1

• Remote users: 0

• Connectivity: Wired

• KVM technology: Digital & analog

• Max operating distance: 10 ft

Memory / Storage

• (Not applicable — hardware switch)

Ports & Interfaces

• USB ports: 6

• USB support: Yes

• HDMI: 2 ports

• DisplayPort: 10 ports

• DVI: No

• VGA: No

• PS/2: 4 ports

• RJ‑45 network ports: None

• Management port: No

Physical Characteristics

• Weight: 3.7 lb

• Dimensions: 2.2" H × 13.7" W × 5" D

• Rack height: 1U

• Form factor: Desktop

Operating System

• Not applicable (KVM hardware device)

Environmental / Compliance

• NIAP 4.0 certified

• RoHS compliant

• Energy Star: No

Included Accessories

• Power supply

• Documentation and standard package contents (as listed)
